Mastervolt AC Master Pure Sine Wave Inverter 2500W

$2,500.00

AC Master 24/2500

The AC Master series is easy to install and delivers full output, even under
the most demanding conditions. The pure sine wave technology provides
an outstanding power quality, ensuring the correct functioning of sensitive
equipment. The usage of high frequency switching technology eliminates
any annoying humming and buzzing sounds.

Representing complete value for money, these ruggedly built inverters
provide essential home comforts when your far from the nearest grid
connection.

Features

Pure sine wave technology protects sensitive equipment.
Delivers full output at high peak power under the most demanding conditions.
Variable speed fan for quiet operation at low power.
Automatic power saving system for extended runtime.
Compact and lightweight design, saving valuable installation time.
Reliable and safe operation; protected against over-temperature, overload, short circuit,
high or low battery voltage.
Suitable for marine & mobile use.
Optional remote control - see below linked remote
Combine 2 up to 15 units to obtain high power or 3-phase systems.
Integrated transfer system, switches automatically between AC power sources.
General

Output voltage: 230/240 V - 50/60 Hz (selectable)
Output waveform: true sine
Nominal battery voltage: 12 V
Continuous power at 40 C / 104 F, cos phi: 1 2500 W
Peak load (3 sec.): < 3000 W
Peak load (< 0.2 sec.): < 4000 W
AC connection hardwired + plug connection
Efficiency: 88 %
Parallel configuration: yes, up to 15 units
3-Phase configuration: yes, 3 units
Display/read-out: LED indication: battery voltage, status
Alarms: potential free alarm contact
Dimensions, hxwxd: 283 x 436 x 128 mm
Weight: 8 kg
Approvals: CE, E-mark
Optional: remote control - see below linked remote
